Plasma Cutter TL-50C | Non-Touch Pilot Arc NHF Version

Plasma Cutter TL-50C | Non-Touch Pilot Arc NHF Version

Regular price $419.99
Regular price Sale price $419.99
Sale Sold out
Shipping calculated at checkout.

SPECIFICATION

· Input Voltage:110V/220V
· Input Current:33.3A(110V)/20.1A(220V)
· Rated Duty Cycle:60%(50A)
· Protection Class:IP21S
· Insulation Class:F

HIGHLIGHT FEATURES

1. Non-HF Start, comes without interference and is safe and ideal for general use, friendly to the surrounding electrical machine and human health.
2. Non-touch pilot arc technology allows to cut without touching the tips to the metal. Better cutting quality and longer consumable life.
3. Built-in post flow, when stop cutting, the air runs on to cool the consumable of the plasma cutter torch to extend consumable life.
4. Up to 50A output current can cut maximum 1/2” ideal clean cut. Suitable for stainless steel, alloy steel, mild steel, copper.
5. Equipped with digital display and regulator in front of the panel, read the air pressure value and current easier.

SHIPPING & RETURNS & WARRANTY

Free return and replace within 30 days. We make sure you have enough time to explore the machine.

The average shipping time is 5 days.

We have warehouses located in southern California and northern Kentucky to manage all shipping and returns.

We cover all quality-related issues in two years and provide lifetime technical support for other problems.

For orders made on Tooliom website only.

support@tooliom.com

View full details

TOOLIOM TL-50C/NHF

1. Non-touch pilot arc, torch head does not need to touch the metal plate, then it will start arc.
2. With post flow function, can be adjusted by yourself extend or shorten the cooling time of the torch head.
3. Up tp 50A output, can handle 1/2" Clean Cut at 220v.
4. Dual-Voltage, allows for connection to 110volt or 220volt.
5. The regulator is installed in front of the panel, can read the air pressure value easier.

  • NON-TOUCH POLIT ARC

    · Incorporates non-touch pilot arc cutting processes, cutting effect is very ideal and can finish the work regardless if the material is very rough, rusty, greasy, dirty, spray painted, etc. Meanwhile longer consumable life.

  • Non-High Frequency

    · Reliable plasma arc initiation without high frequency, greatly reduces the electromagnetic interference caused by high frequency and high voltage discharge.

  • Post Flow Function

    · Built-in post flow function, the adjustment time range is 0-10 seconds. This can be adjusted by yourself extend or shorten the cooling time of the torch head, effectively provide cooling, and extend the working life of consumables.

  • Front Air Pressure Regulator

    · The regulator and digital display are installed in front of the panel, can read the air pressure value and current easy and convenient.

  • Wide Application

    · Widely used for cutting stainless steel, mild steel, copper and other metal materials.

  • Package Included

    · TL-50C/NHF Plasma Cutter
    · IPT40 Plasma Torch
    · 110 Volt to 220 Volt Power Cord Adapter
    · 10' Work Clamp
    · Gas Hose 8'
    · Hose Clamp Hoop
    · Instruction
